oxr_session_action_context Struct Reference

This holds all of the action state that belongs on the session level. More...

#include <oxr/actions/oxr_session_action_context.h>

Collaboration diagram for oxr_session_action_context:

Public Member Functions
XRT_CHECK_RESULT XrResult	oxr_session_action_context_init (struct oxr_session_action_context *action_context, struct xrt_system_devices *xsysd, struct xrt_space_overseer *xso)
	Initialize the action context for a session.
XRT_NONNULL_ALL void	oxr_session_action_context_fini (struct oxr_session_action_context *action_context)
	Finalize and cleanup the action context for a session.
XRT_NONNULL_ALL bool	oxr_session_action_context_has_attached_act_sets (const struct oxr_session_action_context *action_context)
	Check if action sets have been attached to the action context.
XRT_NONNULL_ALL bool	oxr_session_action_context_find_set (struct oxr_session_action_context *action_context, uint32_t act_set_key, struct oxr_action_set_attachment **out_act_set_attached)
	Helper to find action set attachment.

Data Fields
struct u_hashmap_int *	act_sets_attachments_by_key
	A map of action set key to action set attachments.
struct oxr_action_set_attachment *	act_set_attachments
	An array of action set attachments that this session owns.
size_t	action_set_attachment_count
	Length of oxr_session_action_context::act_set_attachments.
struct oxr_suggested_profile_array	profiles_on_attachment
	Clone of suggested binding profiles at action set/session attachment, this is mandated by the OpenXR specification.
struct oxr_binding_registry *	binding_registry
	Binding registry used to resolve this session action context.
uint64_t	dynamic_roles_generation_id
	Cache of the last known system roles generation_id.
struct os_mutex	sync_actions_mutex
	Protects access to dynamic_roles_generation_id during sync actions.
struct oxr_priority_group_cache	priority_group_cache
struct oxr_io_cache	io_cache
XrPath	left
XrPath	right
XrPath	head
XrPath	gamepad
XrPath	eyes

Detailed Description

This holds all of the action state that belongs on the session level.

Future extensions might enable multiple action contexts per session.

Member Function Documentation

oxr_session_action_context_find_set()

XRT_NONNULL_ALL bool oxr_session_action_context_find_set	(	struct oxr_session_action_context *	action_context,
		uint32_t	act_set_key,
		struct oxr_action_set_attachment **	out_act_set_attached
	)

Helper to find action set attachment.

Returns

true if the action set was found, false otherwise

References act_sets_attachments_by_key.

oxr_session_action_context_fini()

XRT_NONNULL_ALL void oxr_session_action_context_fini

(

struct oxr_session_action_context *

action_context

)

Finalize and cleanup the action context for a session.

Safe to call after a failed oxr_session_action_context_init; only resources that init successfully created are torn down.

References act_set_attachments, act_sets_attachments_by_key, action_set_attachment_count, binding_registry, profiles_on_attachment, sync_actions_mutex, and u_hashmap_int_empty().

oxr_session_action_context_has_attached_act_sets()

XRT_NONNULL_ALL bool oxr_session_action_context_has_attached_act_sets

(

const struct oxr_session_action_context *

action_context

)

Check if action sets have been attached to the action context.

Returns

true if action sets are attached, false otherwise

References act_set_attachments.

Referenced by oxr_xrAttachSessionActionSets().

oxr_session_action_context_init()

XRT_CHECK_RESULT XrResult oxr_session_action_context_init	(	struct oxr_session_action_context *	action_context,
		struct xrt_system_devices *	xsysd,
		struct xrt_space_overseer *	xso
	)

Initialize the action context for a session.

References act_set_attachments, act_sets_attachments_by_key, action_set_attachment_count, OXR_FOR_EACH_VALID_SUBACTION_PATH, sync_actions_mutex, and U_ZERO.

Field Documentation

act_set_attachments

struct oxr_action_set_attachment* oxr_session_action_context::act_set_attachments

An array of action set attachments that this session owns.

If non-null, this means action sets have been attached to this session.

Referenced by oxr_action_sync_data_with_context(), oxr_session_action_context_fini(), oxr_session_action_context_has_attached_act_sets(), oxr_session_action_context_init(), oxr_session::oxr_session_attach_action_sets(), and session_clear_action_bindings().

act_sets_attachments_by_key

struct u_hashmap_int* oxr_session_action_context::act_sets_attachments_by_key

A map of action set key to action set attachments.

If non-null, this means action sets have been attached to this session, since this map points to elements of oxr_session_action_context::act_set_attachments

Referenced by oxr_action_set_attachment::oxr_action_set_attachment_teardown(), oxr_session_action_context_find_set(), oxr_session_action_context_fini(), and oxr_session_action_context_init().

action_set_attachment_count

size_t oxr_session_action_context::action_set_attachment_count

Length of oxr_session_action_context::act_set_attachments.

Referenced by oxr_action_sync_data_with_context(), oxr_session_action_context_fini(), oxr_session_action_context_init(), oxr_session::oxr_session_attach_action_sets(), and session_clear_action_bindings().

binding_registry

struct oxr_binding_registry* oxr_session_action_context::binding_registry

Binding registry used to resolve this session action context.

Referenced by oxr_session::oxr_action_get_input_source_localized_name(), oxr_session_action_context_fini(), and oxr_session::oxr_session_attach_action_sets().

dynamic_roles_generation_id

uint64_t oxr_session_action_context::dynamic_roles_generation_id

Cache of the last known system roles generation_id.

Referenced by oxr_action_sync_data_with_context().

profiles_on_attachment

struct oxr_suggested_profile_array oxr_session_action_context::profiles_on_attachment

Clone of suggested binding profiles at action set/session attachment, this is mandated by the OpenXR specification.

It says that the suggested binding profiles should be snapshotted when action sets are attached to the session.

oxr_session_attach_action_sets

Referenced by oxr_session_action_context_fini(), and oxr_session::oxr_session_attach_action_sets().

sync_actions_mutex

struct os_mutex oxr_session_action_context::sync_actions_mutex

Protects access to dynamic_roles_generation_id during sync actions.

Referenced by oxr_action_sync_data_with_context(), oxr_session_action_context_fini(), and oxr_session_action_context_init().

---

The documentation for this struct was generated from the following file:

• state_trackers/oxr/actions/oxr_session_action_context.h
