A helper to implement a xrt_system, takes care of multiplexing events to sessions. More...

#include </builds/monado/monado/src/xrt/base/b_system.h>

Inheritance diagram for b_system:

Collaboration diagram for b_system:

[legend]

Public Member Functions
struct b_system *	b_system_create (void)
	Create a b_system, creates a fully working system.

void	b_system_add_session (struct b_system bsys, struct xrt_session xs, struct xrt_session_event_sink *xses)
	Add a xrt_session to be tracked and to receive multiplexed events.

void	b_system_remove_session (struct b_system bsys, struct xrt_session xs, struct xrt_session_event_sink *xses)
	Remove a xrt_session from tracking, it will no longer receive events, the given `xses` needs to match when it was added.

void	b_system_broadcast_event (struct b_system bsys, const union xrt_session_event xse)
	Broadcast event to all sessions under this system.

void	b_system_set_system_compositor (struct b_system bsys, struct xrt_system_compositor xsysc)
	Set the system compositor, used in the xrt_system_create_session call.

void	b_system_fill_properties (struct b_system bsys, const char name)
	Fill system properties.

Static Public Member Functions
static void	b_system_destroy (struct b_system **bsys_ptr)
	Destroy an b_system_create allocated b_system - helper function.

Static Public Member Functions inherited from xrt_system
static xrt_result_t	xrt_system_create_session (struct xrt_system xsys, const struct xrt_session_info xsi, struct xrt_session out_xs, struct xrt_compositor_native out_xcn)
	Create a xrt_session and optionally a xrt_compositor_native for this system.

static XRT_NONNULL_ALL void	xrt_system_destroy (struct xrt_system **xsys_ptr)
	Destroy an xrt_system - helper function.

Data Fields
struct xrt_system	base

struct xrt_session_event_sink	broadcast
	Pushes events to all sessions created from this system.

struct {

struct os_mutex mutex

uint32_t count
	Number of session and event sink pairs. More...

uint32_t capacity
	Capacity of the session array. More...

struct b_system_session_pair * pairs
	Array of session and event sink pairs. More...

}	sessions

struct xrt_system_compositor *	xsysc
	Used to implement xrt_system::create_session, can be NULL.

Data Fields inherited from xrt_system
xrt_result_t(*	create_session )(struct xrt_system xsys, const struct xrt_session_info xsi, struct xrt_session out_xs, struct xrt_compositor_native out_xcn)
	Create a xrt_session and optionally a xrt_compositor_native for this system.

void(*	destroy )(struct xrt_system *xsys)
	Destroy the system, must be destroyed after system devices and system compositor has been destroyed.

struct xrt_system_properties	properties

Protected Member Functions
bool	b_system_init (struct b_system bsys, void(destroy_fn)(struct xrt_system *))
	Inits a b_system struct when used as a parent class, only to be used by base class.

void	b_system_fini (struct b_system *bsys)
	Finalizes a b_system struct when used as a parent class, only to be used by base class.

Detailed Description

A helper to implement a xrt_system, takes care of multiplexing events to sessions.

Member Function Documentation

◆ b_system_destroy()

static void b_system_destroy ( struct b_system ** bsys_ptr )

inlinestatic

Destroy an b_system_create allocated b_system - helper function.

Parameters

[in,out] bsys_ptr A pointer to the b_system_create allocated struct pointer.

Will destroy the system devices if *bsys_ptr is not NULL. Will then set *bsys_ptr to NULL.

References xrt_system::destroy.

Field Documentation

◆ broadcast

struct xrt_session_event_sink b_system::broadcast

Pushes events to all sessions created from this system.

Referenced by b_system_init(), and sdl_system_devices_init().

◆ capacity

uint32_t b_system::capacity

Capacity of the session array.

Referenced by b_system_add_session(), and b_system_init().

◆ count

uint32_t b_system::count

Number of session and event sink pairs.

Referenced by b_system_add_session(), b_system_broadcast_event(), b_system_fini(), and b_system_remove_session().

◆ pairs

struct b_system_session_pair* b_system::pairs

Array of session and event sink pairs.

Referenced by b_system_add_session(), b_system_broadcast_event(), b_system_fini(), b_system_init(), and b_system_remove_session().

◆ xsysc

struct xrt_system_compositor* b_system::xsysc

Used to implement xrt_system::create_session, can be NULL.

This field should be set with b_system_set_system_compositor.

Referenced by b_system_set_system_compositor().

The documentation for this struct was generated from the following file:

base/b_system.h
